JFUMPC160AG-12900HKS
JF
System Physical Standard Configuration: | ||||||
Type | Details | Descriptions | ||||
Main structure | Form Factor | Aluminium alloy+Plastic | ||||
Dimensions | 358*253*21mm | |||||
Weight | about 2.1KG | |||||
Color | Black | |||||
LCD | Screen Size | 16" | ||||
Screen Resolution | 2560*1600 or 1920*1080 ,IPS （Optional） | |||||
Touchpad | HID-I2C | YES | ||||
Fan | YES | |||||
Fingerprints | / | |||||
Battery | Type | Rechargeable Lithium-ion polymer battery 15.2V | ||||
Capacity | 5800mAh/88.16Wh | |||||
Working Time | 5Hrs(Max. Brightness) | |||||
System Hardware Configuration: | ||||||
Type | Details | Descriptions | ||||
CPU | Optional | Intel®i9-12900HK | CPU Frequency | Max. 5GHZ | ||
Cores | 14Cores20Threads | |||||
TDP | 45W | |||||
integrated graphics | Intel® Iris® Xe Graphics eligible | |||||
integrated GPU Frequency | Max. 1.45GHz | |||||
GPU | Optional | NVDIA RTX3060 | Memory Size | 6GB | ||
Memory Type | GDDR6 | |||||
TGP | 120W | |||||
Boost Frequency | 1530MHz | |||||
Memory | Capacity | SODIMM*2 Maximum Support 64GB（Optional） | ||||
Camera | Front | 3.3V USB 2M | ||||
Rear | / | |||||
Speaker | Built-in | Stereo Speakers 8Ω/1.2W | ||||
Micphone | Built-in | Double Digital Microphone | ||||
Hall switch | Built-in | TRUE | ||||
Trubo Key | on Keyboard | Support 3 different power gear | ||||
Network Connections: | ||||||
Type | Details | Descriptions | ||||
WIFI/BT Module | WIFI | M.2 (2230) AX101- Support 802.11B/G/N/AC&AX （Optional） | ||||
Bluetooth version | BT 5.2 | |||||
Ethernet Network | RJ45 | 1000Mbps | ||||
Interface Configuration: | ||||||
Type | Details | Descriptions | ||||
Storage | SSD | M.2(2280) *2 ,One Support PCIe Gen4&SATA3.0; The other support PCIe4.0 | ||||
SIM Card Slot | Data Storage | / | ||||
USB Interface | Support Data Transfer | USB3.2 Gen2*1 & USB3.2 Gen1*3 | ||||
TypeC Interface | USB-C | TypeC*1 Support Data Transfer&DP Output&Charge(Supports Thunderbolt 4) | ||||
Headphone Jack | Music Output | ∮ 3.5mm Microphone*1 + ∮ 3.5mm headphone*1 | ||||
HDMI Interface | Video Output | HDMI 2.1 | ||||
Keyboard | Input Device | Backlit Keyboard | ||||
DC Interface | Power supply | 19.5V9.23A(180W) | ||||
TF Card Slot | Extended external storage | / | ||||
Main Accessories: | ||||||
Type | Details | Descriptions | ||||
Power adapter | Standard Configuration | DC DIAMETER: ∮5.5mm | ||||
Inputting | 100-240V~2.3A 50/60HZ | |||||
Output | 19.5V9.23A(180W) | |||||
Software Configuration: | ||||||
Type | Details | Descriptions | ||||
Operating System | Windows | Windows 10/Windows 11 | ||||
